BDCOM 24 Port 10/1000 Mbps POE + 2 TX Gigabit Multi-Functional PoE Switch

Item Code: BD-S1526-24P

  • Non-blocking switching architecture, and line-speed forwarding of all ports
  • Large buffer design, ensures smooth playback of high-definition videos
  • Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control
20 (EA) in Stock

Status: In Stock

EA
Comments or instructions

Overview

Overview

BDCOM S1500-P CCTV Series is a multi-functional unmanaged full-gigabit PoE switch with large buffer capacity. The product is primarily applied in access layer of CCTV and WLAN. BDCOM S1500-P series caters to the needs of different-scale deployments in multiple industries such as finance, education, hospitality, healthcare, transportation, energy and manufacturing, empowering the establishment of simplified and secured network.

Specifications

Specifications

Specifications for: BD-S1526-24P: BDCOM 24 Port 10/1000 Mbps POE + 2 TX Gigabit Multi-Functional PoE Switch
Switching capacity56Gbps
MAC2K
Buffer size4Mb
PoE Port24 Gigabit
Uplink RJ452 Gigabit
Uplink SFP2 Gigabit
Dimensions (mm)320x207x45
PoE budget≤285W
PoE standard802.3af/at, maximum output of 30W per port
Power supplyBuilt-in AC: 100~240V, 50/60Hz
Working modeDefault mode, CCTV mode (supports watchdog)
Environment requirementsOperating temperature/humidity:-10°C-45°C, 10%-90% non-condensing

Storage temperature/humidity: -40°C-70°C, 5%-95% non-condensing
FanFanless
Lightning protection4KV
