VSSL MX Series Single-zone, 2-Channel 1U Powered Amplifier with 140W
Details
Details
The VSSL MA.1 is a powerful, single-zone streaming amplifier built for the way you listen today. Delivering 140 watts per channel with modern connectivity like HDMI eARC, Wi-Fi 5, and Bluetooth LE Audio, the MA.1 makes it easy to enjoy incredible sound from any source in your home. Whether streaming your favorite playlist, connecting your TV, or integrating into a smart home system, the MA.1 brings performance, flexibility, and simplicity together in one sleek device.
- Premium Streaming App
- 140 Watts RMS
- Works with VSSL Ecosystem
- Native Streaming
- Wireless inputs from AirPlay 2, Google Cast, Spotify Connect and Bluetooth
- WiFi Certified (Wi-Fi 5 802.11 a/b/g/n/ac)
Experience incredible sound with the VSSL MA.1, a sleek, single-zone streaming amplifier delivering up to 140W per channel at 4Ω or 8Ω. Packed with the latest tech, including HDMI eARC, Wi-Fi 5, and Bluetooth LE Audio with Auracast, the MA.1 oers crystal-clear, high-resolution audio and over 50% better performance and 3x more power output over the previous generation. Designed with simplicity in mind, the MA.1 combines easy setup and intuitive operation with fast responsiveness. It integrates tightly with top streaming platforms like Apple Music, Spotify, YouTube Music, and more, allowing users to stream what they love with minimal eort. The MS.1 features full driver support for leading control systems, including Control4, Crestron, Elan, RTI, and URC, making it ideal for professional installations. As part of the VSSL ecosystem, the MA.1 connects eortlessly with other VSSL devices through the VSSL CNCT™ app, creating a unified whole-home audio experience. With VSSL NSYT™, a powerful remote management application, installers can access and troubleshoot any MX Series device from anywhere in the world, significantly speeding up service and delivering the pinnacle of customer experience. The VSSL MA.1 isn't just a new product—it's the beginning of a new era of distributed audio with the MX Series.
Key Features
- 125W per channel at 8Ω & 200W at 4Ω
- HDMI eARC for seamless TV audio integration
- Wi-Fi 6 + Bluetooth LE Audio with Auracast for faster, clearer wireless connections
- On-board streaming: AirPlay 2, Google Cast, Spotify Connect,
- Easy setup with VSSL CNCT™ app including multi-room and source sharing
- Seamless integration with leading control platforms
| Specifications for: VSSL-MA-1: VSSL MX Series Single-zone, 2-Channel 1U Powered Amplifier with 140W | |
|---|---|
| Zones | 1 |
| Channels | 2 |
| Amplifier | Class D |
| Power | 125W @ 8Ω RMS |
| Power | 200W @ 4Ω RMS |
| Inputs | (1) Analog, (1) Optical, (1) Digital Coax, (1) HDMI eARC, (1) IR, (1) Network, (1) USB |
| Wireless Inputs | AirPlay 2, Google Cast, Spotify Connect, Bluetooth |
| Bluetooth | v5.3, LE Audio |
| WiFi | Wi-Fi 5 802.11 a/b/g/n/ac |
| Outputs | (1) Analog, (1) Optical, (1) Subwoofer, (1) Network |
| Sub Out | RCA, Adjustable crossover 40–120 Hz or bypass for full range |
| EQ | 5-band adjustable |
| S/N Ratio | >98 dB A-weighted |
| Frequency Response | 20–20,000 Hz |
| Onboard Music Services | Pandora, SiriusXM, TuneIn, and more |
| Dimensions | 8.7" W × 1.6" H × 10.6" D (220 mm W × 40 mm H × 270 mm D) |
| Weight | 3.7 lbs (1.7 kg) |
| Power Requirements | 100–240V ~ 50/60V 100W |
